FUSION H-SERIES WINGS MKII

Description

The Fusion H-Series Wings MKII represent the ultimate in efficiency, speed, and progression. Thanks to their ultra-thin profile and unmatched torsional stiffness (PMI core and Pre-Preg carbon), they deliver effortless pumping and glide whether for wing foiling, kite foiling, or prone foiling. The completely redesigned wing tips allow safe maneuvers even in turns: the foil re-engages smoothly without cavitation (SINTEF research). The ergonomic connection between fuselage and mast maximizes system stiffness while remaining easy to assemble. The high aspect ratio offers excellent top speed but also superior maneuverability compared to traditional foils. The brass through-bolt increases stiffness at the joint, giving a direct feel, especially with larger wings. All H-Series foils are fully modular and compatible with stabilizers and front wings from both the X-Series and H-Series.

Technical Features

• HIGH ASPECT design
• PMI core and Pre-Preg carbon sheets
• Brass through-bolt for maximum torsional stiffness
• Tapered fuselage-to-mast connection for solidity and quick assembly
• Fully modular and compatible with all CAB Fusion front wings and stabilizers (X-Series & H-Series)
• Available sizes: H550cm², H700cm², H800cm², H850cm², H1000cm², H1050cm², H1300cm²
• SKU: K3FWHFWNG055XXX
• Ultra-thin and lightweight profile
• Wing tips designed for smooth release/re-engagement without cavitation

Foil Guide – Choosing the Right Size

• Small (H550-800): For advanced riders, high speeds, and maximum reactivity in both kite and prone foiling.
• Medium (H850-H1050): Ideal balance of glide, carving, pumping, and great versatility (wing/prone/kite).
• Large (H1300): For light wind, heavier riders, or those who want extended pumping/upwind drive (wing/surf).

Foil Guide – Frequently Asked Questions (Q&A)

Which size is best for a beginner?

A mid-range option (H850-H1050) is stable and versatile, ideal for learning in many conditions.

When is the H1300 needed?

When the wind is very light or the rider is over 80kg; it ensures lift and easy pumping.

Small sizes, what are they for?

High-level kite and prone foiling, ideal for those seeking extreme maneuverability and high speed.

Is the system really modular?

Yes, you can freely combine X-Series and H-Series front wings and stabilizers.

Build Guide – Step-by-Step Assembly

1. Choose the front wing: Select the surface (H550-1300) according to your weight, level, and discipline.
2. Assembly: Align the wing and fuselage properly, insert and tighten the brass through-bolt.
3. Stabilizer: Mount your choice; all Cabrinha X/H-Series stabilizers are compatible.
4. Mast: Connect the mast to the fuselage (tapered connection, solid and easy).
5. Final check: Make sure all screws are tightened and secure before use.

Build Guide – Q&A

Does it require special maintenance?

Yes, rinse with fresh water and check screws after use in saltwater.

What tools are needed?

Torx or hex keys included in the Cabrinha kit.

Can I mix X-Series and H-Series?

Yes, all front wings and stabilizers are cross-compatible.

Where can I find manuals and support?

Check the official website or the manual included in the kit.
